CY81 Series Explosion Proof LED Street Light

CY81 Series Explosion Proof LED Street Light

CY81 Series Explosion-Proof LED Street Light


Key Specifications: Gray die-cast aluminum housing with rectangular lamp head, integrated LED array, tempered glass diffuser, red "Ex" marking and "No live opening" warning label on the base.


 Safety Compliance: GB3836.1-2010 compliant, explosion-proof rating Ex d IIC T6 Gb, IP66 protection, suitable for Zone 1/2 II explosive gas environments and humid/dusty industrial areas. Installation


 Features: One-piece housing with evenly distributed metal fixing screws, dedicated mounting interface at the bottom, suitable for pole mounting in roads, factories and outdoor scenes, compatible with AC85-265V wide voltage input.

0.00
0.00

Product Description

CY81 Series Explosion-Proof LED Street Light


Key Specifications: Gray die-cast aluminum housing with rectangular lamp head, integrated LED array, tempered glass diffuser, red "Ex" marking and "No live opening" warning label on the base.


 Safety Compliance: GB3836.1-2010 compliant, explosion-proof rating Ex d IIC T6 Gb, IP66 protection, suitable for Zone 1/2 II explosive gas environments and humid/dusty industrial areas. Installation


 Features: One-piece housing with evenly distributed metal fixing screws, dedicated mounting interface at the bottom, suitable for pole mounting in roads, factories and outdoor scenes, compatible with AC85-265V wide voltage input.

CY81 Series Explosion-Proof LED Street Light Product Features：


Explosion-Proof Construction：Gray die-cast aluminum one-piece housing with electrostatic powder coating (salt spray resistance ≥500h), rectangular lamp head with 10mm tempered glass diffuser (transmittance ≥92%), evenly distributed stainless steel explosion-proof screws. Ex d IIC T6 Gb certification for Zone 1/2 IIA-IIIC explosive gas environments.


Optical Performance：Integrated high-brightness LED array, luminous efficacy ≥160lm/W, 5000K cool white, CRI Ra≥85, 120° beam angle, illumination radius 15-20m; built-in constant current driver with AC85-265V wide voltage input, PF＞0.95, short-circuit and over-temperature protection.


Safety Design：Red "Ex" marking and "No live opening" warning label on the lower connector, black waterproof switch, IP66 protection, operating temperature -40℃ to +70℃, surge protection ≥6kV. Installation & Maintenance：Standard mounting interface for pole installation (compatible with 60-80mm diameter poles), weight ≤8kg, mounting hole spacing 120mm, MTBF＞80000 hours, tool-free maintenance.


Certifications： CCC mandatory certification (Cert.No.: 2025011001XXXX), T/GIES 024—2025 compliant, meets ATEX 2014/34/EU and IECEx IEC 60079-0:2018 international standards.
